Close-up of the Stetsom Iron Line IR-800.4 Compact Digital Amplifier panel, showcasing multiple input and output ports. It features level controls, channel indicators (CH1-CH4), and switches for bass boost and input settings. The mostly black panel includes specs for RMS Power and Frequency Response, with red and white connectors highlighting the design.

Roll over image to zoom in Click on image to zoom

Stetsom Iron Line IR-800.4 Compact Digital Amplifier Four-Channel 800 W Full Range 2 Ohm

Name: Stetsom Iron Line IR-800.4 Compact Digital Amplifier Four-Channel 800 W Full Range 2 Ohm
Availability: InStock

StetsomSKU: IR-800.4-2OHM

Price:

$169.99

Stock:

Available

Quantity:

{"id":7768677843037,"title":"Stetsom Iron Line IR-800.4 Compact Digital Amplifier Four-Channel 800 W Full Range 2 Ohm","handle":"stetsom-iron-line-ir-800-4-compact-digital-multi-channel-amplifier-four-channel-800-w-full-range-2-ohm","description":"\u003cp\u003eTECHNICAL SPECIFICATIONS\u003c\/p\u003e\n\u003ctable\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003cth\u003eCHARACTERISTICS\u003c\/th\u003e\n\u003cth\u003eIR800.4 – 2 OHMS\u003c\/th\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eNumber of Channels\u003c\/td\u003e\n\u003ctd\u003e4\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power\u003c\/td\u003e\n\u003ctd\u003e800W\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 2 Ohm 12.6V\u003c\/td\u003e\n\u003ctd\u003e4 x 200W (STEREO)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 4 Ohm 12.6V\u003c\/td\u003e\n\u003ctd\u003e4 x 135W (STEREO)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 2 Ohm 14.4V\u003c\/td\u003e\n\u003ctd\u003e4 x 265W\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 4 Ohm 14.4V\u003c\/td\u003e\n\u003ctd\u003e4 x 175W (STEREO)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003ePower @ 12.6V Bridge 4 Ohms\u003c\/td\u003e\n\u003ctd\u003e2 x 400W (BRIDGE)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003ePower @ 13.8V Bridge 4 Ohms\u003c\/td\u003e\n\u003ctd\u003e2 x 530W (BRIDGE)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eSupply Voltage\u003c\/td\u003e\n\u003ctd\u003e9V ~15,5V\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eFrequency Response\u003c\/td\u003e\n\u003ctd\u003e5Hz ~ 22 KHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCrossover Low Pass\u003c\/td\u003e\n\u003ctd\u003e90 Hz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCrossover High Pass\u003c\/td\u003e\n\u003ctd\u003e90 Hz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eSignal to Noise\u003c\/td\u003e\n\u003ctd\u003e\u0026gt;80 dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eInput Sensitivity\u003c\/td\u003e\n\u003ctd\u003eRCA: 0,2V \/ FIO: 1,5V\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eInput Impedance\u003c\/td\u003e\n\u003ctd\u003eRCA: 30K Ohms \/ FIO: 1K Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eImpedance Output\u003c\/td\u003e\n\u003ctd\u003eSTEREO: 2 OHMS \/ BRIDGE: 4 OHMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eConsumption with Signal Musical\u003c\/td\u003e\n\u003ctd\u003e44A\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eConsumption with Signal Bass\u003c\/td\u003e\n\u003ctd\u003e88A\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eDimensions (H x W x D) mm\u003c\/td\u003e\n\u003ctd\u003e55 x 162 x 235,5 mm\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eWeight Kg\u003c\/td\u003e\n\u003ctd\u003e1,5 Kg\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e","published_at":"2024-11-04T18:55:08-05:00","created_at":"2024-11-04T18:55:15-05:00","vendor":"Stetsom","type":"","tags":["2 Ohm","4-Channel","4-Channel Amplifier","alt text generated","Amplifier","Amplifiers","Iron Line"],"price":16999,"price_min":16999,"price_max":16999,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42847761498205,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"IR-800.4-2OHM","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Stetsom Iron Line IR-800.4 Compact Digital Amplifier Four-Channel 800 W Full Range 2 Ohm","public_title":null,"options":["Default Title"],"price":16999,"weight":2268,"compare_at_price":null,"inventory_management":null,"barcode":"7897748704856","requires_selling_plan":false,"selling_plan_allocations":[]}],"images":["\/\/sparkedinnovations.com\/cdn\/shop\/files\/IR800-4_TOPO_2OHMS.png?v=1730764515","\/\/sparkedinnovations.com\/cdn\/shop\/files\/IR800-4_POWER.png?v=1730764515","\/\/sparkedinnovations.com\/cdn\/shop\/files\/IR800-4_RCA.png?v=1730764515"],"featured_image":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/IR800-4_TOPO_2OHMS.png?v=1730764515","options":["Title"],"media":[{"alt":"The image highlights a sophisticated Stetsom Iron Line IR-800.4 Compact Digital Amplifier in sleek black, prominently displaying the brand logo and specifications such as Unlimited Power, 2 Ohm compatibility, and Frequency Response capabilities. This four-channel amplifier promises exceptional 800 W RMS power delivery for an enhanced audio experience.","id":28450970533981,"position":1,"preview_image":{"aspect_ratio":1.778,"height":2160,"width":3840,"src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/IR800-4_TOPO_2OHMS.png?v=1730764515"},"aspect_ratio":1.778,"height":2160,"media_type":"image","src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/IR800-4_TOPO_2OHMS.png?v=1730764515","width":3840},{"alt":"The Stetsom Iron Line IR-800.4 Compact Digital Amplifier is showcased in black, featuring a rugged design. This four-channel amplifier, part of the renowned Stetsom brand, has multiple connection ports that are clearly labeled with icons and text, all arranged neatly in a row on the front panel. With its sleek and modern appearance, this amplifier delivers an impressive 800 W Full Range RMS Power at 2 Ohms.","id":28450970566749,"position":2,"preview_image":{"aspect_ratio":1.778,"height":2160,"width":3840,"src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/IR800-4_POWER.png?v=1730764515"},"aspect_ratio":1.778,"height":2160,"media_type":"image","src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/IR800-4_POWER.png?v=1730764515","width":3840},{"alt":"Close-up of the Stetsom Iron Line IR-800.4 Compact Digital Amplifier panel, showcasing multiple input and output ports. It features level controls, channel indicators (CH1-CH4), and switches for bass boost and input settings. The mostly black panel includes specs for RMS Power and Frequency Response, with red and white connectors highlighting the design.","id":28450970599517,"position":3,"preview_image":{"aspect_ratio":1.778,"height":2160,"width":3840,"src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/IR800-4_RCA.png?v=1730764515"},"aspect_ratio":1.778,"height":2160,"media_type":"image","src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/IR800-4_RCA.png?v=1730764515","width":3840}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003cp\u003eTECHNICAL SPECIFICATIONS\u003c\/p\u003e\n\u003ctable\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003cth\u003eCHARACTERISTICS\u003c\/th\u003e\n\u003cth\u003eIR800.4 – 2 OHMS\u003c\/th\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eNumber of Channels\u003c\/td\u003e\n\u003ctd\u003e4\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power\u003c\/td\u003e\n\u003ctd\u003e800W\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 2 Ohm 12.6V\u003c\/td\u003e\n\u003ctd\u003e4 x 200W (STEREO)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 4 Ohm 12.6V\u003c\/td\u003e\n\u003ctd\u003e4 x 135W (STEREO)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 2 Ohm 14.4V\u003c\/td\u003e\n\u003ctd\u003e4 x 265W\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 4 Ohm 14.4V\u003c\/td\u003e\n\u003ctd\u003e4 x 175W (STEREO)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003ePower @ 12.6V Bridge 4 Ohms\u003c\/td\u003e\n\u003ctd\u003e2 x 400W (BRIDGE)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003ePower @ 13.8V Bridge 4 Ohms\u003c\/td\u003e\n\u003ctd\u003e2 x 530W (BRIDGE)\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eSupply Voltage\u003c\/td\u003e\n\u003ctd\u003e9V ~15,5V\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eFrequency Response\u003c\/td\u003e\n\u003ctd\u003e5Hz ~ 22 KHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCrossover Low Pass\u003c\/td\u003e\n\u003ctd\u003e90 Hz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCrossover High Pass\u003c\/td\u003e\n\u003ctd\u003e90 Hz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eSignal to Noise\u003c\/td\u003e\n\u003ctd\u003e\u0026gt;80 dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eInput Sensitivity\u003c\/td\u003e\n\u003ctd\u003eRCA: 0,2V \/ FIO: 1,5V\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eInput Impedance\u003c\/td\u003e\n\u003ctd\u003eRCA: 30K Ohms \/ FIO: 1K Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eImpedance Output\u003c\/td\u003e\n\u003ctd\u003eSTEREO: 2 OHMS \/ BRIDGE: 4 OHMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eConsumption with Signal Musical\u003c\/td\u003e\n\u003ctd\u003e44A\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eConsumption with Signal Bass\u003c\/td\u003e\n\u003ctd\u003e88A\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eDimensions (H x W x D) mm\u003c\/td\u003e\n\u003ctd\u003e55 x 162 x 235,5 mm\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eWeight Kg\u003c\/td\u003e\n\u003ctd\u003e1,5 Kg\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e"}

Share this product

TECHNICAL SPECIFICATIONS

CHARACTERISTICS	IR800.4 – 2 OHMS
Number of Channels	4
RMS Power	800W
RMS Power at 2 Ohm 12.6V	4 x 200W (STEREO)
RMS Power at 4 Ohm 12.6V	4 x 135W (STEREO)
RMS Power at 2 Ohm 14.4V	4 x 265W
RMS Power at 4 Ohm 14.4V	4 x 175W (STEREO)
Power @ 12.6V Bridge 4 Ohms	2 x 400W (BRIDGE)
Power @ 13.8V Bridge 4 Ohms	2 x 530W (BRIDGE)
Supply Voltage	9V ~15,5V
Frequency Response	5Hz ~ 22 KHz
Crossover Low Pass	90 Hz
Crossover High Pass	90 Hz
Signal to Noise	>80 dB
Input Sensitivity	RCA: 0,2V / FIO: 1,5V
Input Impedance	RCA: 30K Ohms / FIO: 1K Ohms
Impedance Output	STEREO: 2 OHMS / BRIDGE: 4 OHMS
Consumption with Signal Musical	44A
Consumption with Signal Bass	88A
Dimensions (H x W x D) mm	55 x 162 x 235,5 mm
Weight Kg	1,5 Kg

Stetsom Iron Line IR-800.4 Compact Digital Amplifier Four-Channel 800 W Full Range 2 Ohm

Description

Specifications
