Description
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | IR 280.4 |
|---|---|
| Number of Channels | 4 |
| RMS Power at 2 Ohm 13.8V | 4 x 70W RMS (280W RMS) |
| RMS Power at 4 Ohm 13.8V | 4 x 40W RMS (180W RMS) |
| Power @ 13.8V Bridge 4 Ohms | 2 x 140W RMS (280W RMS) |
| Supply Voltage | 9 ~ 15V |
| Frequency Response | 10Hz ~48KHz |
| Crossover Low Pass | FLAT / LPF 90Hz / BASS BOOST @+12dB |
| Signal to Noise | >90dB |
| Harmonic Distortion | > 0,03% THD |
| Input Sensitivity | 250mV |
| Input Impedance | 24KOhms |
| Impedance Output | 2 Ohms Stereo / 4 Ohms Bridge |
| Consumption with Signal Musical | 11,5A |
| Consumption with Signal Bass | 23A |
| Dimensions (H x W x D) mm | 48 x 78 x 112 |
| Weight Kg | 0,355 Kg |
