Description
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | HL1200.4 – 2 OHMS |
|---|---|
| Number of Channels | 4 |
| RMS Power at 2 Ohm 12.6V | 4 x 300W RMS |
| RMS Power at 4 Ohm 12.6V | 4 x 165W RMS |
| RMS Power at 2 Ohm 13.8V | 4 x 320W RMS |
| RMS Power at 4 Ohm 13.8V | 4 x 170W RMS |
| Power @ 12.6V Bridge 4 Ohms | 2 x 600W RMS |
| Supply Voltage | 9V ~ 15V DC |
| Frequency Response | 10Hz ~ 26KHz |
| Crossover Low Pass | 90Hz |
| Crossover High Pass | 90Hz |
| Signal to Noise | >90dB |
| Harmonic Distortion | <0,3 % THD |
| Input Sensitivity | 200mV |
| Input Impedance | 14K Ohms |
| Impedance Output | STEREO: 2 OHMS / BRIDGE: 4 OHMS |
| Consumption with Signal Musical | 53A |
| Consumption with Signal Bass | 106A |
| Dimensions (H x W x D) mm | 66 x 206 x 216 mm |
| Weight Kg | 1,95 Kg |
Specifications
