Stetsom BRAVO FULL 8K Digital Full-Range Amplifier Mono One-Channel Class D 8000 W 2 Ohm

Roll over image to zoom in Click on image to zoom

Stetsom BRAVO FULL 8K Digital Full-Range Amplifier Mono One-Channel Class D 8000 W 2 Ohm

Name: Stetsom BRAVO FULL 8K Digital Full-Range Amplifier Mono One-Channel Class D 8000 W 2 Ohm
Availability: InStock

StetsomSKU: BRAVO-FULL-8K-2OHM

Price:

$570.99

Stock:

Available

Quantity:

{"id":7768676401245,"title":"Stetsom BRAVO FULL 8K Digital Full-Range Amplifier Mono One-Channel Class D 8000 W 2 Ohm","handle":"stetsom-bravo-full-8k-digital-full-range-amplifier-mono-one-channel-class-d-8000-w-2-ohm","description":"\u003cp\u003eThe BRAVO FULL line was developed for automotive sound lovers who seek maximum performance in FULL-RANGE amplifiers.\u003c\/p\u003e\n\u003cp\u003eIts frequency response from 10Hz to 12kHz offers audio quality and definition, and can be used with subwoofers, woofers, drivers, and tweeters.\u003c\/p\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003cp\u003eTECHNICAL SPECIFICATIONS\u003c\/p\u003e\n\u003ctable\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003cth\u003eCHARACTERISTICS\u003c\/th\u003e\n\u003cth\u003eBRAVO FULL 8000 – 2 OHMS\u003c\/th\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eNumber of Channels\u003c\/td\u003e\n\u003ctd\u003e1\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power\u003c\/td\u003e\n\u003ctd\u003e8000W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 2 Ohm 12.6V\u003c\/td\u003e\n\u003ctd\u003e8000W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 4 Ohm 12.6V\u003c\/td\u003e\n\u003ctd\u003e4200W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 2 Ohm 14.4V\u003c\/td\u003e\n\u003ctd\u003e8700W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 4 Ohm 14.4V\u003c\/td\u003e\n\u003ctd\u003e4400W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eSupply Voltage\u003c\/td\u003e\n\u003ctd\u003e9V ~ 16V DC\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eFrequency Response\u003c\/td\u003e\n\u003ctd\u003e10Hz ~ 12KHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCrossover Low Pass\u003c\/td\u003e\n\u003ctd\u003e90Hz ~ 12KHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCrossover High Pass\u003c\/td\u003e\n\u003ctd\u003e10Hz ~ 90Hz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eSignal to Noise\u003c\/td\u003e\n\u003ctd\u003e\u0026gt;90dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eInput Sensitivity\u003c\/td\u003e\n\u003ctd\u003e200mV\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eInput Impedance\u003c\/td\u003e\n\u003ctd\u003e13K Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eImpedance Output\u003c\/td\u003e\n\u003ctd\u003e2 Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eConsumption with Signal Musical\u003c\/td\u003e\n\u003ctd\u003e360A\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eConsumption with Signal Bass\u003c\/td\u003e\n\u003ctd\u003e720A\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eDimensions (H x W x D) mm\u003c\/td\u003e\n\u003ctd\u003e80 x 231,5 x 419 mm\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eWeight Kg\u003c\/td\u003e\n\u003ctd\u003e6,0 Kg\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e","published_at":"2024-11-04T18:52:51-05:00","created_at":"2024-11-04T18:53:03-05:00","vendor":"Stetsom","type":"","tags":["1-Channel","2 Ohm","Amplifier","Amplifiers","Amplifiers\/Monoblock (1-Channel) Amps","BRAVO FULL","Mono Amplifier","Monoblock"],"price":57099,"price_min":57099,"price_max":57099,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42847758876765,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"BRAVO-FULL-8K-2OHM","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Stetsom BRAVO FULL 8K Digital Full-Range Amplifier Mono One-Channel Class D 8000 W 2 Ohm","public_title":null,"options":["Default Title"],"price":57099,"weight":5443,"compare_at_price":null,"inventory_management":null,"barcode":"7897748705334","requires_selling_plan":false,"selling_plan_allocations":[]}],"images":["\/\/sparkedinnovations.com\/cdn\/shop\/files\/bravofull8k.jpg?v=1730764383","\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO-FULL_8000_TOPO_1OHM_e4f5e06b-780d-4aac-a604-f09cbb73bb88.png?v=1730764383","\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO_FULL_8000_POWER_999d7f18-d4cc-419b-86b1-2beb870c1437.png?v=1730764383","\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO_FULL_8000_RCA.png?v=1730764383"],"featured_image":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/bravofull8k.jpg?v=1730764383","options":["Title"],"media":[{"alt":null,"id":28450965618781,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1280,"width":1280,"src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/bravofull8k.jpg?v=1730764383"},"aspect_ratio":1.0,"height":1280,"media_type":"image","src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/bravofull8k.jpg?v=1730764383","width":1280},{"alt":null,"id":28450965651549,"position":2,"preview_image":{"aspect_ratio":1.778,"height":2160,"width":3840,"src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO-FULL_8000_TOPO_1OHM_e4f5e06b-780d-4aac-a604-f09cbb73bb88.png?v=1730764383"},"aspect_ratio":1.778,"height":2160,"media_type":"image","src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO-FULL_8000_TOPO_1OHM_e4f5e06b-780d-4aac-a604-f09cbb73bb88.png?v=1730764383","width":3840},{"alt":null,"id":28450965684317,"position":3,"preview_image":{"aspect_ratio":1.778,"height":2160,"width":3840,"src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO_FULL_8000_POWER_999d7f18-d4cc-419b-86b1-2beb870c1437.png?v=1730764383"},"aspect_ratio":1.778,"height":2160,"media_type":"image","src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO_FULL_8000_POWER_999d7f18-d4cc-419b-86b1-2beb870c1437.png?v=1730764383","width":3840},{"alt":null,"id":28450965717085,"position":4,"preview_image":{"aspect_ratio":1.778,"height":2160,"width":3840,"src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO_FULL_8000_RCA.png?v=1730764383"},"aspect_ratio":1.778,"height":2160,"media_type":"image","src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO_FULL_8000_RCA.png?v=1730764383","width":3840}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003cp\u003eThe BRAVO FULL line was developed for automotive sound lovers who seek maximum performance in FULL-RANGE amplifiers.\u003c\/p\u003e\n\u003cp\u003eIts frequency response from 10Hz to 12kHz offers audio quality and definition, and can be used with subwoofers, woofers, drivers, and tweeters.\u003c\/p\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003cp\u003eTECHNICAL SPECIFICATIONS\u003c\/p\u003e\n\u003ctable\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003cth\u003eCHARACTERISTICS\u003c\/th\u003e\n\u003cth\u003eBRAVO FULL 8000 – 2 OHMS\u003c\/th\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eNumber of Channels\u003c\/td\u003e\n\u003ctd\u003e1\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power\u003c\/td\u003e\n\u003ctd\u003e8000W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 2 Ohm 12.6V\u003c\/td\u003e\n\u003ctd\u003e8000W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 4 Ohm 12.6V\u003c\/td\u003e\n\u003ctd\u003e4200W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 2 Ohm 14.4V\u003c\/td\u003e\n\u003ctd\u003e8700W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 4 Ohm 14.4V\u003c\/td\u003e\n\u003ctd\u003e4400W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eSupply Voltage\u003c\/td\u003e\n\u003ctd\u003e9V ~ 16V DC\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eFrequency Response\u003c\/td\u003e\n\u003ctd\u003e10Hz ~ 12KHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCrossover Low Pass\u003c\/td\u003e\n\u003ctd\u003e90Hz ~ 12KHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCrossover High Pass\u003c\/td\u003e\n\u003ctd\u003e10Hz ~ 90Hz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eSignal to Noise\u003c\/td\u003e\n\u003ctd\u003e\u0026gt;90dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eInput Sensitivity\u003c\/td\u003e\n\u003ctd\u003e200mV\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eInput Impedance\u003c\/td\u003e\n\u003ctd\u003e13K Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eImpedance Output\u003c\/td\u003e\n\u003ctd\u003e2 Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eConsumption with Signal Musical\u003c\/td\u003e\n\u003ctd\u003e360A\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eConsumption with Signal Bass\u003c\/td\u003e\n\u003ctd\u003e720A\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eDimensions (H x W x D) mm\u003c\/td\u003e\n\u003ctd\u003e80 x 231,5 x 419 mm\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eWeight Kg\u003c\/td\u003e\n\u003ctd\u003e6,0 Kg\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e"}

Share this product

The BRAVO FULL line was developed for automotive sound lovers who seek maximum performance in FULL-RANGE amplifiers.

Its frequency response from 10Hz to 12kHz offers audio quality and definition, and can be used with subwoofers, woofers, drivers, and tweeters.

TECHNICAL SPECIFICATIONS

CHARACTERISTICS	BRAVO FULL 8000 – 2 OHMS
Number of Channels	1
RMS Power	8000W RMS
RMS Power at 2 Ohm 12.6V	8000W RMS
RMS Power at 4 Ohm 12.6V	4200W RMS
RMS Power at 2 Ohm 14.4V	8700W RMS
RMS Power at 4 Ohm 14.4V	4400W RMS
Supply Voltage	9V ~ 16V DC
Frequency Response	10Hz ~ 12KHz
Crossover Low Pass	90Hz ~ 12KHz
Crossover High Pass	10Hz ~ 90Hz
Signal to Noise	>90dB
Input Sensitivity	200mV
Input Impedance	13K Ohms
Impedance Output	2 Ohms
Consumption with Signal Musical	360A
Consumption with Signal Bass	720A
Dimensions (H x W x D) mm	80 x 231,5 x 419 mm
Weight Kg	6,0 Kg

Stetsom BRAVO FULL 8K Digital Full-Range Amplifier Mono One-Channel Class D 8000 W 2 Ohm
