Description
The BRAVO FULL line was developed for automotive sound lovers who seek maximum performance in FULL-RANGE amplifiers.
Its frequency response from 10Hz to 12kHz offers audio quality and definition, and can be used with subwoofers, woofers, drivers, and tweeters.
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | BRAVO FULL 5000 – 2 OHMS |
|---|---|
| Number of Channels | 1 |
| RMS Power | 5000W RMS |
| RMS Power at 2 Ohm 12.6V | 5000W RMS |
| RMS Power at 4 Ohm 12.6V | 2600W RMS |
| RMS Power at 1 Ohm 14.4V | 5300W RMS |
| RMS Power at 2 Ohm 14.4V | 3000W RMS |
| Supply Voltage | 9V ~ 16V DC |
| Frequency Response | 10Hz ~ 12Khz |
| Crossover Low Pass | 90Hz ~ 12KHz |
| Crossover High Pass | 10Hz ~ 90Hz |
| Signal to Noise | >90dB |
| Input Sensitivity | 200mV |
| Input Impedance | 12KOhms |
| Impedance Output | 2 Ohms |
| Consumption with Signal Musical | 227A |
| Consumption with Signal Bass | 445A |
| Dimensions (H x W x D) mm | 80 x 231,5 x 333 mm |
| Weight Kg | 4,25 Kg |
