Stetsom BRAVO FULL 5K Digital Full-Range Amplifier Mono One-Channel Class D 5000 W 1 Ohm

Roll over image to zoom in Click on image to zoom

Stetsom BRAVO FULL 5K Digital Full-Range Amplifier Mono One-Channel Class D 5000 W 1 Ohm

Name: Stetsom BRAVO FULL 5K Digital Full-Range Amplifier Mono One-Channel Class D 5000 W 1 Ohm
Availability: InStock

StetsomSKU: BRAVO-FULL-5K-1OHM

Price:

$469.99

Stock:

Available

Quantity:

{"id":7768676696157,"title":"Stetsom BRAVO FULL 5K Digital Full-Range Amplifier Mono One-Channel Class D 5000 W 1 Ohm","handle":"stetsom-bravo-full-5k-digital-full-range-amplifier-mono-one-channel-class-d-5000-w-1-ohm","description":"\u003cp\u003eThe BRAVO FULL line was developed for automotive sound lovers who seek maximum performance in FULL-RANGE amplifiers.\u003c\/p\u003e\n\u003cp\u003eIts frequency response from 10Hz to 12kHz offers audio quality and definition, and can be used with subwoofers, woofers, drivers, and tweeters.\u003c\/p\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003cp\u003eTECHNICAL SPECIFICATIONS\u003c\/p\u003e\n\u003ctable\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003cth\u003eCHARACTERISTICS\u003c\/th\u003e\n\u003cth\u003eBRAVO FULL 5000 – 1 OHM\u003c\/th\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eNumber of Channels\u003c\/td\u003e\n\u003ctd\u003e1\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power\u003c\/td\u003e\n\u003ctd\u003e5000W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 1 Ohm 12.6V\u003c\/td\u003e\n\u003ctd\u003e5000W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 2 Ohm 12.6V\u003c\/td\u003e\n\u003ctd\u003e2800W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 1 Ohm 14.4V\u003c\/td\u003e\n\u003ctd\u003e5300W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 2 Ohm 14.4V\u003c\/td\u003e\n\u003ctd\u003e3300W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eFrequency Response\u003c\/td\u003e\n\u003ctd\u003e10Hz ~ 12KHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCrossover Low Pass\u003c\/td\u003e\n\u003ctd\u003e90Hz ~ 12KHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCrossover High Pass\u003c\/td\u003e\n\u003ctd\u003e10Hz ~ 90Hz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eSignal to Noise\u003c\/td\u003e\n\u003ctd\u003e\u0026gt;90dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eInput Sensitivity\u003c\/td\u003e\n\u003ctd\u003e200mV\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eInput Impedance\u003c\/td\u003e\n\u003ctd\u003e12K Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eImpedance Output\u003c\/td\u003e\n\u003ctd\u003e1 OHM\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eConsumption with Signal Musical\u003c\/td\u003e\n\u003ctd\u003e242A\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eConsumption with Signal Bass\u003c\/td\u003e\n\u003ctd\u003e485A\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eDimensions (H x W x D) mm\u003c\/td\u003e\n\u003ctd\u003e80 x 231,5 x 333 mm\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eWeight Kg\u003c\/td\u003e\n\u003ctd\u003e4,25 Kg\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e","published_at":"2024-11-04T18:53:24-05:00","created_at":"2024-11-04T18:53:34-05:00","vendor":"Stetsom","type":"","tags":["1 Ohm","1-Channel","Amplifier","Amplifiers","Amplifiers\/Monoblock (1-Channel) Amps","BRAVO FULL","Mono Amplifier","Monoblock"],"price":46999,"price_min":46999,"price_max":46999,"available":true,"price_varies":false,"compare_at_price":null,"compare_at_price_min":0,"compare_at_price_max":0,"compare_at_price_varies":false,"variants":[{"id":42847759368285,"title":"Default Title","option1":"Default Title","option2":null,"option3":null,"sku":"BRAVO-FULL-5K-1OHM","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"Stetsom BRAVO FULL 5K Digital Full-Range Amplifier Mono One-Channel Class D 5000 W 1 Ohm","public_title":null,"options":["Default Title"],"price":46999,"weight":3175,"compare_at_price":null,"inventory_management":null,"barcode":"7897748705303","requires_selling_plan":false,"selling_plan_allocations":[]}],"images":["\/\/sparkedinnovations.com\/cdn\/shop\/files\/bravofull5k_e3a785f3-fcb3-45a2-baae-c695c1584082.jpg?v=1730764414","\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO-FULL_5000_TOPO_1OHM.png?v=1730764414","\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO_FULL_8000_POWER_8b1fcb46-b966-492b-892a-f713c97aae5e.png?v=1730764414","\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO_FULL_8000_RCA_83850f30-7bb3-4419-8f0c-b1d8360cffef.png?v=1730764414"],"featured_image":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/bravofull5k_e3a785f3-fcb3-45a2-baae-c695c1584082.jpg?v=1730764414","options":["Title"],"media":[{"alt":null,"id":28450966732893,"position":1,"preview_image":{"aspect_ratio":1.0,"height":1280,"width":1280,"src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/bravofull5k_e3a785f3-fcb3-45a2-baae-c695c1584082.jpg?v=1730764414"},"aspect_ratio":1.0,"height":1280,"media_type":"image","src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/bravofull5k_e3a785f3-fcb3-45a2-baae-c695c1584082.jpg?v=1730764414","width":1280},{"alt":null,"id":28450966765661,"position":2,"preview_image":{"aspect_ratio":1.778,"height":2160,"width":3840,"src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO-FULL_5000_TOPO_1OHM.png?v=1730764414"},"aspect_ratio":1.778,"height":2160,"media_type":"image","src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO-FULL_5000_TOPO_1OHM.png?v=1730764414","width":3840},{"alt":null,"id":28450966798429,"position":3,"preview_image":{"aspect_ratio":1.778,"height":2160,"width":3840,"src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO_FULL_8000_POWER_8b1fcb46-b966-492b-892a-f713c97aae5e.png?v=1730764414"},"aspect_ratio":1.778,"height":2160,"media_type":"image","src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO_FULL_8000_POWER_8b1fcb46-b966-492b-892a-f713c97aae5e.png?v=1730764414","width":3840},{"alt":null,"id":28450966831197,"position":4,"preview_image":{"aspect_ratio":1.778,"height":2160,"width":3840,"src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO_FULL_8000_RCA_83850f30-7bb3-4419-8f0c-b1d8360cffef.png?v=1730764414"},"aspect_ratio":1.778,"height":2160,"media_type":"image","src":"\/\/sparkedinnovations.com\/cdn\/shop\/files\/BRAVO_FULL_8000_RCA_83850f30-7bb3-4419-8f0c-b1d8360cffef.png?v=1730764414","width":3840}],"requires_selling_plan":false,"selling_plan_groups":[],"content":"\u003cp\u003eThe BRAVO FULL line was developed for automotive sound lovers who seek maximum performance in FULL-RANGE amplifiers.\u003c\/p\u003e\n\u003cp\u003eIts frequency response from 10Hz to 12kHz offers audio quality and definition, and can be used with subwoofers, woofers, drivers, and tweeters.\u003c\/p\u003e\n\u003cp\u003e \u003c\/p\u003e\n\u003cp\u003eTECHNICAL SPECIFICATIONS\u003c\/p\u003e\n\u003ctable\u003e\n\u003ctbody\u003e\n\u003ctr\u003e\n\u003cth\u003eCHARACTERISTICS\u003c\/th\u003e\n\u003cth\u003eBRAVO FULL 5000 – 1 OHM\u003c\/th\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eNumber of Channels\u003c\/td\u003e\n\u003ctd\u003e1\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power\u003c\/td\u003e\n\u003ctd\u003e5000W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 1 Ohm 12.6V\u003c\/td\u003e\n\u003ctd\u003e5000W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 2 Ohm 12.6V\u003c\/td\u003e\n\u003ctd\u003e2800W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 1 Ohm 14.4V\u003c\/td\u003e\n\u003ctd\u003e5300W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eRMS Power at 2 Ohm 14.4V\u003c\/td\u003e\n\u003ctd\u003e3300W RMS\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eFrequency Response\u003c\/td\u003e\n\u003ctd\u003e10Hz ~ 12KHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCrossover Low Pass\u003c\/td\u003e\n\u003ctd\u003e90Hz ~ 12KHz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eCrossover High Pass\u003c\/td\u003e\n\u003ctd\u003e10Hz ~ 90Hz\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eSignal to Noise\u003c\/td\u003e\n\u003ctd\u003e\u0026gt;90dB\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eInput Sensitivity\u003c\/td\u003e\n\u003ctd\u003e200mV\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eInput Impedance\u003c\/td\u003e\n\u003ctd\u003e12K Ohms\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eImpedance Output\u003c\/td\u003e\n\u003ctd\u003e1 OHM\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eConsumption with Signal Musical\u003c\/td\u003e\n\u003ctd\u003e242A\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eConsumption with Signal Bass\u003c\/td\u003e\n\u003ctd\u003e485A\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eDimensions (H x W x D) mm\u003c\/td\u003e\n\u003ctd\u003e80 x 231,5 x 333 mm\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003ctr\u003e\n\u003ctd\u003eWeight Kg\u003c\/td\u003e\n\u003ctd\u003e4,25 Kg\u003c\/td\u003e\n\u003c\/tr\u003e\n\u003c\/tbody\u003e\n\u003c\/table\u003e"}

Share this product

The BRAVO FULL line was developed for automotive sound lovers who seek maximum performance in FULL-RANGE amplifiers.

Its frequency response from 10Hz to 12kHz offers audio quality and definition, and can be used with subwoofers, woofers, drivers, and tweeters.

TECHNICAL SPECIFICATIONS

CHARACTERISTICS	BRAVO FULL 5000 – 1 OHM
Number of Channels	1
RMS Power	5000W RMS
RMS Power at 1 Ohm 12.6V	5000W RMS
RMS Power at 2 Ohm 12.6V	2800W RMS
RMS Power at 1 Ohm 14.4V	5300W RMS
RMS Power at 2 Ohm 14.4V	3300W RMS
Frequency Response	10Hz ~ 12KHz
Crossover Low Pass	90Hz ~ 12KHz
Crossover High Pass	10Hz ~ 90Hz
Signal to Noise	>90dB
Input Sensitivity	200mV
Input Impedance	12K Ohms
Impedance Output	1 OHM
Consumption with Signal Musical	242A
Consumption with Signal Bass	485A
Dimensions (H x W x D) mm	80 x 231,5 x 333 mm
Weight Kg	4,25 Kg
