Description
The BRAVO FULL line was developed for automotive sound lovers who seek maximum performance in FULL-RANGE amplifiers.
Its frequency response from 10Hz to 22kHz offers audio quality and definition, and can be used with subwoofers, woofers, drivers, and tweeters.
TECHNICAL SPECIFICATIONS
| CHARACTERISTICS | BRAVO FULL 3000 – 1 OHM |
|---|---|
| Number of Channels | 1 |
| RMS Power | 3000W RMS |
| RMS Power at 1 Ohm 12.6V | 3100W RMS |
| RMS Power at 2 Ohm 12.6V | 2000W RMS |
| RMS Power at 1 Ohm 14.4V | 3500W RMS |
| RMS Power at 2 Ohm 14.4V | 2100W RMS |
| Supply Voltage | 9V ~ 16V DC |
| Frequency Response | 10Hz ~ 22KHz |
| Crossover Low Pass | 90Hz ~ 22KHz |
| Crossover High Pass | 10Hz ~ 90Hz |
| Input Sensitivity | 200mV |
| Input Impedance | 18K Ohms |
| Impedance Output | 1 Ohm |
| Consumption with Signal Musical | 160A |
| Consumption with Signal Bass | 320A |
| Dimensions (H x W x D) mm | 80 x 231,5 x 236 mm |
| Weight Kg | 2,90 Kg |
