STETSOM BRAVO FULL 12000 1OHM

The BRAVO FULL line was developed for car audio enthusiasts seeking maximum performance and quality in FULL-RANGE amplifiers.

Its frequency response of 5Hz to 7kHz offers audio quality and definition, allowing it to be used with subwoofers, woofers, drivers, and tweeters.

TECHNICAL SPECIFICATIONS

CHARACTERISTICS	BRAVO FULL 12000 – 1 OHM
Number of Channels	1
RMS Power	12.000W
RMS Power at 1 Ohm 12.6V	12.000W
RMS Power at 2 Ohm 12.6V	7.120W
RMS Power at 1 Ohm 14.4V	12.800W
RMS Power at 2 Ohm 14.4V	8.510W
Supply Voltage	9V ~ 16V DC
Frequency Response	5Hz ~ 7KHz @ 1 Ohm
Crossover Low Pass	90Hz ~ 7KHz
Crossover High Pass	5Hz ~ 90Hz
Signal to Noise	>90dB
Input Sensitivity	200mV
Input Impedance	19K Ohms
Impedance Output	1 OHM
Consumption with Signal Musical	590A
Consumption with Signal Bass	1180A
Dimensions (H x W x D) mm	79,7 x 574 x 231,5 mm
Weight Kg	8,6 Kg
