Description
Features:
- Power Handling: 3000 Watts RMS
- Custom tooled basket
- Custom-tooled ultra-linear spider packs
Specifications:
NS V.6 18
T/S SPECS | NS V.6 18″ D1 | NS V.6 18″ D2 |
---|---|---|
RE (Ohms) | 1.8090 | 3.6629 |
FS (Hz) |
28.6283
|
28.3677 |
VAS (L) | 78.9335 |
82.9318 |
Qes | 0.4955 | 0.4948 |
Qms | 5.2141 | 5.1127 |
Qts | 0.4525 | 0.4511 |
Le (mH) | 1.7089 | 3.3898 |
BL (NA) | 21.7903 | 30.4106 |
Mms (Grams) | 722.9906 |
700.8333 |
Cms (uM/N) | 42.7481 | 44.9135 |
Sens (dB @ 1w/1m) | 87.4738 | 87.5755 |
ENCLOSURE SPECIFICATIONS
Sealed Enclosure | Not Recommended |
Ported Enclosure | 7 cu.ft. net |
Recommended Tuning | 32Hz |
Recommended Port Area | 100 sq.in. |
Displacement | .27 cu. ft. |
Depth | 16.25" |
Outside Diameter | 18.46" |
Cut-Out | 16.68" |
Physical Dimensions | Coming Soon |
Specifications
Product Brand | Sundown Audio |
Coil | Dual 1 Ohm (D1) Dual 2 Ohm (D2) |
Diameter | 18" |
