Momentary Black Halo Ring 12V Push Button Switch SPDT

Save $1.60
Sparked InnovationsSKU: B16-11DTM-PR

Color: Purple
Price:
Sale price$6.40 Regular price$8.00
Stock:
In stock

Description

Universal black aluminum momentary pushbutton switch to activate horns, fuel doors, trunk pops, door solenoids, anything needing a momentary pulse. Illuminates a ring around button head when activated. Can be wired so that the LED illuminates constant or only when the switch is in the on position.

Universal aluminum 12V momentary push button black switch. These types of switches are momentary mechanical switches of the Single Pole Double Throw (SPDT) variety. To activate, press and hold for ON and release for OFF. The halo ring LED light can be wired to be illuminated at all times or only when the switch is held in the ON position.

To have the LED illuminated always:

  • Connect the Normally Open (N.O.) pole to the Positive (+) pole
  • Connect the Positive (+) pole to your Positive (+) 12VDC power source (battery +)
  • Connect the Negative (-) pole to your Negative (-) Ground source
  • Connect the Common (C) pole to your 12V accessory (horn, fuel door, trunk pop, door solenoid, etc.)



To have the LED illuminate only when the button is pressed and held:

  • Connect the Normally Open (N.O.) pole to the Positive (+) pole
  • Connect the Positive (+) pole to your 12V accessory (horn, fuel door, trunk pop, door solenoid, etc.)
  • Connect the Negative (-) pole to your Negative (-) Ground source
  • Connect the Common (C) pole to your Positive (+) 12VDC power source (battery +)

it to activate horns, fuel doors, trunk pops, door solenoids, anything that needs a momentary pulse.

Illuminates a ring around button head when activated. Can be wired so that the LED illuminates constant or only when the switch is in the on position.

IP67 rated for dust and waterproof up to 1 meter. Can be used in automotive, marine, motorcycle, or industrial applications.

Specifications

  • Mounting diameter = 16mm
  • Head diameter = 18mm
  • Mounting depth = 35mm
  • LED operating voltage = 12v DC, range = 9~16v
  • Max switch rating = 3A/250v AC
  • Contacts = 1NO, 1NC
  • LED life = 40,000+ hrs.

Specifications

LED Lifespan 40,000+ hours
Color Blue   Green   Purple   Red   White
Waterproof Rating IP67
Symbol Ring
Switch Type Pushbutton
Switch Contact Type 1NC, 1NO
Product Brand Sparked Innovations
Overall Diameter 18mm
Mounting Hole Diameter 16mm
Mounting Depth 35mm
Maximum Switch Rating 3A/250VAC
LED Operating Voltage 12VDC
